1000V DC Extension Cable with O Shape Contact
Model#: PK10-JT174A
Desc.: Extension Cable with O Shape Contact
https://www.parko-solar.com/1000V-DC-Extension-Cable-with-O-Shape-Contact.html
Products Main Features:
1. High voltage & current endurance capability; use for 1000V system;
2. Good impact resistance & ageing resistance capability; use imported PPO raw material;
3. Lower contact resistance to 0.30 mΩ, contact material: pure copper (99.9%);
4. Innovative seal & waterproof design, meet IP68 (1m,1H) waterproof,
5. High performance for ambient temperature range from -40℃ ~ +85℃, UV resistance, insulation, suitable for long time outdoor use.
6. Good safety performance, TUV test & approved, sell well in Euro & US.
7. Easy & quick for installation, high pull-out force, stable self-locking structure, long working life above to 20 years.
8. Compatible with MC4, EVO2, QC4 etc. PV connectors.
9. Cable length and end can be adjusted per customer requirement.
Specification (Main Technical Parameters):
Rated current | 20A~30A | Insulation material | Sabic PPO |
Rated voltage | 1000V(IEC)/600V(UL) | Material RTI | 110℃ |
Test voltage | 6KV(50Hz.1min) | Ambient temperature range | -40℃~+85℃ |
Contact resistance | ≤0.5mΩ | Suitable wire size range | 2.5mm2~6mm2(14~10AWG) |
Contact material | Copper.Tin plated | PV Cable length | User defined |
Flame class | UL94-V0 | PV Cable Color | Black/Red |
Products Main Size:
Product Application Diagram:
