10Kg Low Torque Brushless Electric Screwdriver Push start type
Brushless DC voltage automatic low torque electric screwdriver series
Model: GW-B3110PF
Torque: 1~10Kgf.cm
Free Speed: HI 1800 / LO 1500 r.p.m
https://www.g-wei.com.cn/10Kg-Low-Torque-Brushless-Electric-Screwdriver-Push-start-type.html
Special Features
➤ The unique structure of the independent patent cooperates with the high-quality brushless motor, the function is more stable and longer durability;
➤ The output speed is stable and the torque is accurate. When the preset torque is reached, the motor automatically stops in order to protect the product security.
➤ Adopt electronic control start-stop technology to get rid of the life limit of mechanical structure and save after-sales cost;
➤ We are using eco-friendly materials on all of our parts and components to protect the earth;
➤ The product is compact and easy to operate, suitable for long-term operation;
➤ There are 4mm, 5mm, 6.35mm (1/4") screwdriver bits for selection
Product Details
Model |
GW-B3060LF |
GW-B3060PF |
GW-B3110LF |
GW-B3110PF |
|
Voltage |
Input: AC 100~240V (50/60Hz), Output: DC LO 24V or HI 30V |
||||
Power |
60W |
||||
Torque |
Kgf.cm |
0.5~6 |
0.5~6 |
1~10 |
1~10 |
Lbf.in |
0.43~5.2 |
0.43~5.2 |
0.87~8.7 |
0.87~8.7 |
|
N.m |
0.05~0.59 |
0.05~0.59 |
0.10~0.98 |
0.10~0.98 |
|
Free Speed(r.p.m) |
HI |
1800 |
1800 |
1800 |
1800 |
LO |
1500 |
1500 |
1500 |
1500 |
|
Suitable screw(mm) |
Machine Screw |
1.4~2.6 |
1.4~2.6 |
1.7~3.0 |
1.7~3.0 |
Tapping Screw |
1.4~2.3 |
1.4~2.3 |
1.7~2.6 |
1.7~2.6 |
|
Weight(g) |
373 |
381 |
373 |
381 |
|
Bit Type |
φ4 |
φ4 |
φ4 |
φ4 |
|
Power Controller |
GW-30DC-60W (4P) |
||||
Cable |
4P |
4P |
4P |
4P |
1kgf.cm=0.098N.m 1kgf.cm=0.868Lbf.in
Dimension
Product details content
1. Brushless electric screwdriver product application scope.
Household appliances, communication equipment, plastics, toys, electronic assembly, etc.
2. Problems to be paid attention to when choosing electric screwdriver:
(1) Simply test its performance and torque, if it exceeds a certain torque, it will jump out, increase the forward and reverse gears to loosen and tighten the screws;
(2) Speed, accuracy, if the speed is too low, it is easy to affect the efficiency. Generally, the better electric screwdriver has several different speed options such as high, medium and low;
(3) Distinguish between home and professional use according to needs. The difference between professional and general home electric screwdrivers is in power. Professional electric screwdrivers have higher power, and household electric screwdrivers have lower power.
3. What are the human faults of brushless electric screwdriver:
(1) The operator does not use it properly, and the power cord is often bent and easily damaged;
(2) There is too much dust in the working environment, which can easily enter the electric screwdriver, causing static electricity and heat;
(3) Throw or drop the electric screwdriver after use;
(4) Pull out the connecting plug between the electric screwdriver and the matching controller and pull the wire hard, which can easily damage the contact plug;
(5) When the electric screwdriver is not in use or is powered off, do not unplug it.
