Gap film laminating machine
Gap film application machine is a high-precision automation equipment, which is mainly used to achieve precise fitting of film, protective film
Function description:
By applying reflective film on the glass, the gaps between the cells and the
strings of the battery components are filled. Through the microstructure on the
substrate, the sunlight in the gaps between the cells is reused by using the
total reflection principle of the glass-air interface, thus improving the
utilization rate of sunlight.
Technical parameters：
| Parameter configuration | |
| Layout | String+piece |
| Size | 6170mm*5000mm*2400mm (length*width*height) |
| Function·Glass longitudinal + transverse gap film | ·Four-sided film ·Module regular glass ·Dual servo drive film |
| Number of film that can be pasted on a string | 7 (14 film heads) |
| Number of film that can be pasted on a piece | 26 (26 film heads) optional |
| Filming accuracy and appearance inspection (optional) | |
| Important parameters·Compatible with 166-230 component versions | |
| Filming cycle | ≤15s |
| Filming accuracy | ±0.2mm |
| Filming yield | >99.5% (actually measured 99.7%) |
| Online/offline filming can be realized | |
| Activity rate | >99.5% (actually measured 99.7%) |
