MA-(3~10MM)×2000MM Steel Coil Slitter
MA-(3~10MM)×2000MM Steel Coil Slitter made from Wuxi Mazs machinery is suitable for coil strip thickness (3-10)mm; while strip width is changeable: 600mm. 1000mm, 1250mm, 1600mm, 2000mm and so on.
https://www.mazsmachine.com/MA-3-10MM-2000MM-Steel-Coil-Slitter.html
General Introduction
– MA-(3~10MM)×2000MM Steel Coil Slitter made from Wuxi Mazs machinery, the line main components : uncoiling machine, guiding device, uncoiling tension unit, coil head shearing, feeding table, looper, disc shearing, guiding roller, machine row transfer roller, clamping device, constant tension coiler, scrap rewinding machine, recoiling machine, etc.
– MA-(3~10MM)×2000MM Steel Coil Slitter is suitable for coil strip thickness (3-10)mm; while strip width is changeable: 600mm. 1000mm, 1250mm, 1600mm, 2000mm and so on.
Detailed Technical Data
– Material of coils: carbon steel, color steel, galvanized steel and etc
– Strip thickness: (3~10)mm
– Strip width: 800~2000mm
– Steel Slitter Inner diameter of coils: ≥Φ508mm
– Max.outer diameter of coils: Φ2000mm
– Steel Slitting Machine Max.coil weight: 35000kgs
– Material of leveling roller: 40Cr
– Steel Slitter shaft: Φ300 x 2050mm
– Material of disc cutter: 6CrW2Si, HRC 55-58
– Steel Slitting Machine Recoiling spindle: Φ610×2100mm
– Slitting speed: (0~60) m/min, adjustable
Machine Main Components
– Feeding trolley – single-arm feeding machine, coil leading device – tilting platform – looper 1 – rectification – disc shear – waste scrap winding – looper 2 – pre-slitting, tension machine, length measuring roller – recoiling – unloading trolley – hydraulic control – electrical control
Specification Form
|
Model |
Thickness |
Coil width |
Coil Weight |
Finished slit |
Max Slitting speed |
|
MA-10 x 2000 |
3-10mm |
800-2000mm |
Max 35T |
Min. 60mm |
60m/min |
|
Note: The data in the form just as reference according to general ranges, we always design and make each sheet slitting line according to each customer's specific requirements, so each customer can buy his own well-content coil slitting machine from us. |
|||||
Production Line Flowing Chart
Machine Photo for Reference
Loading and Packing
Machine will be fixed inside container by steel wire and special PET strap to be , in order to make sure all parts will not move during transportation and avoid any kinds of damage of machine and container.
Our Service and Features
– 1. Design: MAZS have a matured and experienced technical team with rich experience to develop and design the machines according to customer's demand and requirements.
– 2. This is a very perfect and durable equipment. MAZS have more than 20 years experiences in this field.
– 3. This kind of machine has superior quality and reliable service. It has high accuracy and easy operation.
– 4. MAZS supply technical support (both before, during and after sales), production, installation, commissioning and maintenance service to all customers.
– 5. Our product has been exported to many regions and won high reputation because of the high quality reasonable price and reliable service, quick action for after sale service.
