Contact Plate Freezer
Contact plate freezer can quickly freeze products by moving up and down the inside aluminum plates so that the products exchange heat with two plates.
Contact plate freezer can quickly freeze products by moving up and down the
inside aluminum plates so that the products exchange heat with two plates.
Refrigeration system can be equipped as per different requirement of users.
Application field：This plate freezer is suitable for freezing block foods,
such as fish fillet, surimi, shrimp, shellfish and other aquatic products on
land or on fishing boats.
Main Features:
1. Designed to fit in limited space requirements. Easy for installing and
moving.
1. Both sides stainless steel panels. Good insulation and easy for
cleaning.
2. Hydraulic up and down system and aluminum alloy plates.
3. Refrigeration system can be equipped together to save investment.
Small words below the structural diagram:
1、Cylinder Holder
2、Lifting Cylinder
3、Hydraulic Pump
4、Liquid Supply Pipe
5、Suction Pipe
6、Insulated Cabinet
7、Control Box
8、Plate Tractor
9、Evaporating Aluminum Plate
| Model | Freezing capacity (kg/batch) |
No. of plate | Size of plate (mm) |
Tier pitch(mm) | Refrigerant | Refrigeration capacity(kw) | Weight(kg) | Overall dimension(mm) | |
| PA-420 | 420 | 8 | 1250×1260 | 55～100 | R717/R22 | 19 | 1200 | 2300×1560×1600 | |
| PA-900 | 900 | 10 | 2000×1260 | 55～105 | 37 | 3100 | 3300×1900×2900 | ||
| PA-1000 | 1000 | 11 | 2000×1260 | 55～105 | 40 | 3200 | 3300×1900×2900 | ||
| PA-1100 | 1100 | 12 | 2000×1260 | 55～100 | 43 | 3300 | 3300×1900×2900 | ||
| PA-1200 | 1200 | 13 | 2000×1260 | 50～80 | 46 | 3400 | 3300×1900×2900 | ||
| PA-1210※ | 1210 | 12 | 1700×1459 | 55～100 | 43 | 3300 | 3300×1900×3250 | ||
| PA-1300 | 1300 | 14 | 2000×1260 | 55～105 | 49 | 4000 | 3300×1900×3250 | ||
| PA-1430※ | 1430 | 14 | 1700×1459 | 55～105 | 49 | 4000 | 3300×1900×3250 | ||
| PA-1936※ | 1936 | 12 | 2100×1620 | 55～100 | 56 | 3900 | 3300×2060×3250 | ||
| PA-1500 | 1500 | 16 | 2000×1260 | 50～80 | 56 | 4200 | 3300×1900×3250 | ||
| PA-2288※ | 2288 | 14 | 2100×1620 | 55～105 | 64 | 5100 | 3300×2060×3250 | ||
Notes: 1.The freezing capacity is based on freezing fish. 10kg/tray. Tray
size 590mm×390mm×70mm. Those models marked with ※ are 11kg/tray. Tray size:
800mm×255mm×65mm
2.Refrigeration capacity is based on condensing temp. +35℃ and evaporating
temp.-35℃.
3.Freezing time is about 120~240min. It differs by different products.(Inlet
temp.+15℃,outlet core temp -18℃)
