iHF Standard Spur Gear Rack S45C Precision Linear Rack for Printing Machinery

Productfeatures:

The standard spur rack features a 20°pressure angle and is precision-manufactured to deliver reliable linear motion in demanding applications. It is available in two material options: S45C medium carbon steel for superior strength and durability under high loads, and SUS304 stainless steel for excellent corrosion resistance in humid or chemically exposed environments.

Typical Applications:

Ideal for converting rotary motion to precise linear movement in:

· Industrial Automation: CNC machine tool axes, linear actuators, pick-and-place systems, and automated assembly lines.

· Woodworking & Machining: CNC routers, engraving machines, cutting equipment, and material feed systems.

· Packaging & Material Handling: Conveyor positioning gates, lifting mechanisms, and cartesian robot systems.

· Precision Instrumentation: Optical positioning stages, medical device mechanisms, and testing equipment.

This rack series offers a robust solution for applications requiring high rigidity, accurate linear guidance, and long-term operational stability.

Precision Rack:

Product Name	Spur Rack Pressure Angle 20°
Material	S45C/SUS304
Product Model	CD01AF/CD01AA/CD01AU
Tooth Profile	Spur Gear
Transport Package	Cartons
Trademark	iHF
HS Code	8483900090

Manufacturing Process	Casting
Surface Treatment	Blackening
Surface Color	Black
Application	Industrial Automation and Robotics/Woodworking and Stone Processing/Construction Machinery and Logistics Equipment
Specification	Standard
Origin	Dongguan(Mainland)
Production Capacity	500000 PCS/Year

Product Description:

Product	Standard Spur Rack
Customized	OEM, Drawings or Samples Customized
Tooth Profile	Spur Gear
Module	1.0/1.5/2.0/2.5/3.0
Length	20~480
Hole Machining	Bottom Threaded Hole(B)/Side Threaded Hole(S)/Side Counter-bore Hole(H)/No Hole(N)
Heat Treatment	HRC42~46
Surface Treatment	Blackening
Material	S45C/SUS304
Standard	DIN, ISO/GB, AGMA, JIS
Teeth Accuracy	DIN, ISO/GB Class 4, AGMA Class 13, JIS Class 0
Weight	Max 15 Tons
Testing Equipment	Projecting apparatus, salt spray test, durometer, and coating thickness tester, 2D projector
Producing Equipment	CNC machine, automatic lathe macine, stamping machine, CNC milling machine,rolling maching, lasering, tag grinding machine etc.
Machining Process	Gear Hobbing, Gear Milling, Gear shaping, Gear Broaching, Gear Shaving, Gear Grinding and Gear Lapping
Application Industry	Robot industry, Medical industry, Making machine industry, Automation industry, 3C industry equipment, Packaging industry, UAV industry, New energy industry

Application

The spur rack series is suitable for linear motion scenarios across multiple industrial fields, widely applied in positioning drives for CNC machine tools, industrial robots, and automated production lines, feeding mechanisms in woodworking engraving and cutting equipment, conveying and sorting units in packaging and handling systems, as well as transmission systems in precision instruments and medical equipment that require high rigidity, precision, and environmental resistance.
